Machine Gun
German
MG-34
Weight
* 12.1 kg (26.7 lb)
* 19.2 kg (42.3 lb) (with tripod)
Length
* 1,219 mm (48 in)
Barrel length
* 627 mm (24.7 in)
Cartridge: 7.92x57mm Mauser
Action: Recoil operated
Rate of fire: 800-900 rounds/min
Early versions: 600 - 1000 rounds/min selectable on pistol grip.
MG34"S" : 1,700 rounds/min.
MG34/41 : 1,200 rounds/min.
Muzzle velocity: 755 m/s (2,477 ft/s)
Feed system: 50/200-round belts or 75-round drum magazine
Sights: Iron sights
MG-42
Weight 11.57 kg (25.51 lb)
Length 1,120 mm (44.1 in)
Cartridge 7.92x57mm Mauser
Action Recoil-operated, roller-locked
Rate of fire 1,200 rounds/min (varied between 900–1,500 rounds/min with different bolts)
Muzzle velocity 755 m/s (2,477 ft/s)
Effective range 1000 m
Feed system 50 or 250-round belt
USA
M1919 Browning machine gun
Weight: 31 lb (14 kg) (M1919A4)
Length :
* 37.94 in (964 mm) (M1919A4)
* 53 in (1346 mm) (M1919A6)
Barrel length : 24 in (609 mm)
Cartridge
* .30-06 Springfield (U.S.)
* 7.62 x 51 mm NATO (U.S.)
* .303 British
* 8 mm Mauser
Action : Recoil-operated/short-recoil operation
Rate of fire: 400–600 round/min
Muzzle velocity: 2,800 ft/s (853.6 m/s)
Effective range: 1,500 yd (1,370 m) (maximum)
Feed system: 250-round belt
British
Bren light machine gun
Weight: 22.83 lb (10.35 kg)
Length: 42.9 in (1,156 mm), Mk IV
Barrel length: 25 in (635 mm)
Crew 2, firer and magazine/barrel changer
Cartridge: .303 British
7.92x57mm Mauser (for Republic of China in World War II)
7.62x51mm NATO
Action: Gas-operated, tilting bolt
Rate of fire: 500–520 rounds/min
Muzzle velocity: 2440 ft/s (743.7 m/s)
Effective range: 600 yd (550 m)
Maximum range: 1850 yd
Feed system: 30-round detachable box magazine, 100-round detachable pan magazine
===
Vickers MG
Weight: 15 kg (33.07 lb) to 23 kg (50.71 lb) all-up
Length: 1,100 mm (43.31 in.)
Barrel length: 720 mm (28.35 in.)
Cartridge: .303 British
Action: recoil with gas boost
Rate of fire: 450 to 600 round/min
Effective range: 810 yd (740 m)
Maximum range: 4,500 yd (4,100 m) indirect fire
Feed system: 250-round canvas belt
Lewis LMG
Weight 28 pounds (13 kg)
Length 50.5 inches (1,280 mm)
Barrel length 26.5 inches (670 mm)
Width 4.5 inches (110 mm)
Cartridge .303 (7.7x57R)mm, .30-06 (7.62x63)mm
Action Gas operated
Rate of fire 500–600 rounds/min
Muzzle velocity 2440 ft/s
Effective range 880 yards (800 m)
Maximum range 3,500 yards (3,200 m)
Feed system 47 or 97-round drum magazine
Sights Blade and Tangent Leaf
Soviet
PM M1910 Maxim
Weight: 64.3 kg (139.6 lbs)
Length: 1067 mm
Barrel length: 721 mm
Cartridge: 7.62x54mmR
Action: recoil
Rate of fire: 600 round/min
Muzzle velocity: 740 m/s (2,427.2 ft/s)
Feed system: 250 round belt
DEGTYAREV M-27 LIGHT MACHINE GUN
Weight: 9.12 kg (20.11 lb)
Length: DP, DPM - 1,270 mm (50 in), RP-46 - 1,272 mm (50.1 in)
Barrel length: DP, DPM - 604 mm (23.8 in), RP-46 - 605 mm (23.8 in)
Cartridge: 7.62x54mmR
Action: Gas-Operated
Rate of fire: 500 to 600 round/min
Muzzle velocity: 840 m/s (2,755.2 ft/s)
Effective range: ~800 m
Feed system: 47 Round Pan Magazine
Sights: Front: Post w/ ears
Back: Tangent leaf
===
Japanese
Type 99
Weight : 11.4 kg
Length : 1181 mm
Barrel length : 550 mm
Cartridge: 7.7x58mm Arisaka
Action: Gas-operated
Rate of fire: 250 to 900 round/min
Muzzle velocity: 715 m/s (2,300 ft/s)
Feed system: 30 round detachable box magazine
Italy
Breda M37
Weight 17.5 kg
Length 1270 mm
Cartridge 8x59mm RB Breda
Action gas-operated
Rate of fire 460 round/min maximum, 250 rounds/min sustained
Muzzle velocity 900 m/s (2,952 ft/s)
Effective range 1000 m
Feed system 20 round strip
Breda 30
Weight 10.6 kg
Length 1230 mm
Barrel length 450 mm
Cartridge 6.5x52mm Mannlicher-Carcano
Action blowback
Rate of fire ~ 500 round/min
Muzzle velocity 630 m/s (2,066.4 ft/s)
Effective range 800 m
Maximum range 3000 m
Feed system 4 stripper clips of 5 round stripper clip = 20 rounds
German
MG-34
Weight
* 12.1 kg (26.7 lb)
* 19.2 kg (42.3 lb) (with tripod)
Length
* 1,219 mm (48 in)
Barrel length
* 627 mm (24.7 in)
Cartridge: 7.92x57mm Mauser
Action: Recoil operated
Rate of fire: 800-900 rounds/min
Early versions: 600 - 1000 rounds/min selectable on pistol grip.
MG34"S" : 1,700 rounds/min.
MG34/41 : 1,200 rounds/min.
Muzzle velocity: 755 m/s (2,477 ft/s)
Feed system: 50/200-round belts or 75-round drum magazine
Sights: Iron sights
MG-42
Weight 11.57 kg (25.51 lb)
Length 1,120 mm (44.1 in)
Cartridge 7.92x57mm Mauser
Action Recoil-operated, roller-locked
Rate of fire 1,200 rounds/min (varied between 900–1,500 rounds/min with different bolts)
Muzzle velocity 755 m/s (2,477 ft/s)
Effective range 1000 m
Feed system 50 or 250-round belt
USA
M1919 Browning machine gun
Weight: 31 lb (14 kg) (M1919A4)
Length :
* 37.94 in (964 mm) (M1919A4)
* 53 in (1346 mm) (M1919A6)
Barrel length : 24 in (609 mm)
Cartridge
* .30-06 Springfield (U.S.)
* 7.62 x 51 mm NATO (U.S.)
* .303 British
* 8 mm Mauser
Action : Recoil-operated/short-recoil operation
Rate of fire: 400–600 round/min
Muzzle velocity: 2,800 ft/s (853.6 m/s)
Effective range: 1,500 yd (1,370 m) (maximum)
Feed system: 250-round belt
British
Bren light machine gun
Weight: 22.83 lb (10.35 kg)
Length: 42.9 in (1,156 mm), Mk IV
Barrel length: 25 in (635 mm)
Crew 2, firer and magazine/barrel changer
Cartridge: .303 British
7.92x57mm Mauser (for Republic of China in World War II)
7.62x51mm NATO
Action: Gas-operated, tilting bolt
Rate of fire: 500–520 rounds/min
Muzzle velocity: 2440 ft/s (743.7 m/s)
Effective range: 600 yd (550 m)
Maximum range: 1850 yd
Feed system: 30-round detachable box magazine, 100-round detachable pan magazine
===
Vickers MG
Weight: 15 kg (33.07 lb) to 23 kg (50.71 lb) all-up
Length: 1,100 mm (43.31 in.)
Barrel length: 720 mm (28.35 in.)
Cartridge: .303 British
Action: recoil with gas boost
Rate of fire: 450 to 600 round/min
Effective range: 810 yd (740 m)
Maximum range: 4,500 yd (4,100 m) indirect fire
Feed system: 250-round canvas belt
Lewis LMG
Weight 28 pounds (13 kg)
Length 50.5 inches (1,280 mm)
Barrel length 26.5 inches (670 mm)
Width 4.5 inches (110 mm)
Cartridge .303 (7.7x57R)mm, .30-06 (7.62x63)mm
Action Gas operated
Rate of fire 500–600 rounds/min
Muzzle velocity 2440 ft/s
Effective range 880 yards (800 m)
Maximum range 3,500 yards (3,200 m)
Feed system 47 or 97-round drum magazine
Sights Blade and Tangent Leaf
Soviet
PM M1910 Maxim
Weight: 64.3 kg (139.6 lbs)
Length: 1067 mm
Barrel length: 721 mm
Cartridge: 7.62x54mmR
Action: recoil
Rate of fire: 600 round/min
Muzzle velocity: 740 m/s (2,427.2 ft/s)
Feed system: 250 round belt
DEGTYAREV M-27 LIGHT MACHINE GUN
Weight: 9.12 kg (20.11 lb)
Length: DP, DPM - 1,270 mm (50 in), RP-46 - 1,272 mm (50.1 in)
Barrel length: DP, DPM - 604 mm (23.8 in), RP-46 - 605 mm (23.8 in)
Cartridge: 7.62x54mmR
Action: Gas-Operated
Rate of fire: 500 to 600 round/min
Muzzle velocity: 840 m/s (2,755.2 ft/s)
Effective range: ~800 m
Feed system: 47 Round Pan Magazine
Sights: Front: Post w/ ears
Back: Tangent leaf
===
Japanese
Type 99
Weight : 11.4 kg
Length : 1181 mm
Barrel length : 550 mm
Cartridge: 7.7x58mm Arisaka
Action: Gas-operated
Rate of fire: 250 to 900 round/min
Muzzle velocity: 715 m/s (2,300 ft/s)
Feed system: 30 round detachable box magazine
Italy
Breda M37
Weight 17.5 kg
Length 1270 mm
Cartridge 8x59mm RB Breda
Action gas-operated
Rate of fire 460 round/min maximum, 250 rounds/min sustained
Muzzle velocity 900 m/s (2,952 ft/s)
Effective range 1000 m
Feed system 20 round strip
Breda 30
Weight 10.6 kg
Length 1230 mm
Barrel length 450 mm
Cartridge 6.5x52mm Mannlicher-Carcano
Action blowback
Rate of fire ~ 500 round/min
Muzzle velocity 630 m/s (2,066.4 ft/s)
Effective range 800 m
Maximum range 3000 m
Feed system 4 stripper clips of 5 round stripper clip = 20 rounds
Anti Tank Gun
US Bazooka
M1 type
* Length: 54 in (137 cm)
* Caliber: 60 mm (2.36 in)
* Weight: 13.00 lb (5.9 kg)
* Warhead: M6 shaped charge (3.5 lb, 1.59 kg)
* Range
o Maximum: 400 yards (365.76 m)
o Effective: (claimed) 150 yards (137.16 m)
* Crew: 2, operator and loader
3.5-Inch Anti-Tank Rocket Launcher M1
front grip click to hear
Part used to grip the front of the bazooka.
shoulder rest click to hear
Part that holds the bazooka against the shooter’s shoulder.
front sight click to hear
Metal aiming device attached to the front of the barrel.
rear sight click to hear
Graduated aiming device; the rear sight is lined up with the front sight when taking aim.
spring click to hear
Part that controls the firing mechanism.
tube click to hear
Cylindrical tube used to fire projectiles.
==
German
Panzerfaust
Panzerschreck
British
PIAT / Projector, Infantry, Anti Tank
Weight 32 pounds (15 kg)
Length 39 inches (0.99 m)
Muzzle velocity 250 feet (76 m) per second
Effective range 100 yards (91 m)
Maximum range 750 yards (690 m)
Sights aperture sight
Filling HEAT
Filling weight : 2.5 pounds (1.1 kg)
Detonation: mechanism Impact
Projectile: 1.3 kg, hollow charge, with stabilizer fins
Penetration: approximately 75 mm
Australian soldiers in Balipapan Battle
US Bazooka
M1 type
* Length: 54 in (137 cm)
* Caliber: 60 mm (2.36 in)
* Weight: 13.00 lb (5.9 kg)
* Warhead: M6 shaped charge (3.5 lb, 1.59 kg)
* Range
o Maximum: 400 yards (365.76 m)
o Effective: (claimed) 150 yards (137.16 m)
* Crew: 2, operator and loader
3.5-Inch Anti-Tank Rocket Launcher M1
front grip click to hear
Part used to grip the front of the bazooka.
shoulder rest click to hear
Part that holds the bazooka against the shooter’s shoulder.
front sight click to hear
Metal aiming device attached to the front of the barrel.
rear sight click to hear
Graduated aiming device; the rear sight is lined up with the front sight when taking aim.
spring click to hear
Part that controls the firing mechanism.
tube click to hear
Cylindrical tube used to fire projectiles.
==
German
Panzerfaust
Panzerschreck
British
PIAT / Projector, Infantry, Anti Tank
Weight 32 pounds (15 kg)
Length 39 inches (0.99 m)
Muzzle velocity 250 feet (76 m) per second
Effective range 100 yards (91 m)
Maximum range 750 yards (690 m)
Sights aperture sight
Filling HEAT
Filling weight : 2.5 pounds (1.1 kg)
Detonation: mechanism Impact
Projectile: 1.3 kg, hollow charge, with stabilizer fins
Penetration: approximately 75 mm
Australian soldiers in Balipapan Battle
Automatic Rifle
(STG) Sturmgewehr 44
Weight 5.22 kg (11.5 lb)
Length 940 mm (37 in)
Barrel length 419 mm (16.5 in)
Cartridge 7.92x33mm Kurz
Action Gas-operated, tilting bolt
Rate of fire 500-600 rounds/min
Muzzle velocity 685 m/s (2,247 ft/s)
Effective range 300 m
Feed system 30-round detachable box magazine
Sights Adjustable sights, rear: V-notch; front: hooded post
Maschinenpistole 43, Maschinenpistole 44 dan Sturmgewehr 44 (MP43, MP44 dan StG44) adalah senapan otomatis selective-fire yang dikembangkan oleh Jerman pada Perang Dunia II, dalam program Maschinenkarabiner (karabin mesin) mereka.
MP43, MP44, dan StG44 adalah senapan yang hampir serupa, dengan sedikit perbedaan pada produksi dan waktu pembuatan. Ketiganya dikembangkan dari Mkb 42(H). Perbedaan nama ini ada karena rumitnya penamaan senjata pada era Nazi Jerman. 'StG' adalah singkatan dari Sturmgewehr (senapan serbu, assault rifle), yang menggabungkan sifat-sifat karabin, submachine gun, dan senapan otomatis. Setelah dipakainya StG44, istilah ini menjadi lumrah untuk mendeskripsikan tipe senjata seperti ini.
Senapan ini memakai peluru 7,92 x 33 mm, yang juga dikenal dengan nama 7,92 mm Kurz (berarti 'pendek'). Peluru ini adalah modifikasi dari peluru standar 7,92 × 57 mm Mauser. Melalui kombinasi dengan kemampuan selective-fire, senjata ini menghasilkan semburan setingkat submachine gun, dengan akurasi dan daya setingkat senapan K98 Mauser pada jarak dekat. Walau begitu, StG44 memiliki jangkauan dan daya yang lebih rendah daripada senapan-senapan pada era itu. Karakter ini mengikuti hasil studi yang dipakai oleh Wehrmacht pada saat itu, yaitu bahwa hampir semua pertempuran terjadi pada jarak kurang dari 300 meter dan mayoritas kurang dari 200 meter. Senapan lain dianggap terlalu besar kekuatannya. Senjata StG44 berhasil membuktikan keunggulannya pada Front Timur sewaktu ia banyak dipakai dan dianggap lebih baik daripada senapan lain pada saat itu.
Sebelum memakai nama MP44 atau Stg 44,dia menyandang nama Maschinenkarabiner 43.Senapan tersebut pada awalnya tidak diresmikan oleh Hitler sebelum menunjukan aksinya di Front Timur.Setelah menunjukan kehebatanya,Maschinenkarabiner pun diresmikan oleh Hitler pada tahun 1943 dan mengganti nama menjadi MP43 dan kelak MP44 atau Stg 44. Sebenarnya pemakaian MP44 adalah "sembunyi-sembunyi" kalau-kalau Hitler akan tidak senang dengan senjata tersebut.Angkatan bersenjata Nazi yang menerima senjata tersebut pertama kali adalah, SS Schutzstaffel. Senjata ini pun menjadi favorit SAS Inggris apabila mereka kehabisan peluru Sten atau Brengun.Senjata ini pun dapat menjadi "Light Support Weapon" bagi SAS apabila Brengun mereka habis.
Konon..dari STG-44 inilah yang mengilhami Mikhail Kalashnikov utk menciptakan senapan legendaris AK-47..
===
FG-42, Paratroops Fallschirmjäger rifle
Weight: 4.2 kg (9.3 lb) (Ausführung "E")
4.95 kg (10.9 lb) (Ausführung "G")
Length: 945 mm (37.2 in) (Ausführung "E")
975 mm (38.4 in) (Ausführung "G")
Barrel length: 500 mm (19.7 in)
Cartridge: 7.92x57mm Mauser
Action: Gas-operated, rotating bolt
Rate of fire: Approx. 900 rounds/min (Ausführung "E")
Approx. 750 rounds/min (Ausführung "G")
Muzzle velocity: 740 m/s (2,428 ft/s) (SmK bullet)
Effective range: 450 m
Feed system: 10 or 20-round detachable box magazine
Sights: Iron sights (all models); flip-up front post and folding rear diopter sight; ZFG42 or ZF4 scope
FG-42 hampir sama dgn STG-44 hanya pelurunya setara dgn K98, dan hanya digunakan oleh pasukan Fallschirmjäger (Airbone).
Pict: Battle of Crete
===
USA
M1918 Browning
Weight: 7.25 kg (15.98 lb) (M1918)
Approx. 11 kg (24 lb) (M1922)
8.4 kg (19 lb) (M1918A1)
8.8 kg (19 lb) (M1918A2)
9.0 kg (20 lb) (wz. 1928)
Length: 1,194 mm (47 in) (M1918, M1922, M1918A1)
1,215 mm (47.8 in) (M1918A2)
1,110 mm (43.7 in) (wz. 1928)
Barrel length: 610 mm (24.0 in) (M1918, M1922, M1918A1, M1918A2)
611 mm (24.1 in) (wz. 1928)
Cartridge: .30-06 Springfield (7.62x63mm) (M1918, M1922, M1918A1, M1918A2)
7.92x57mm Mauser (wz. 1928)
7.65x53mm Belgian Mauser (FN Mle 1930, FN Mle D)
7x57mm Mauser
6.5x55mm (Kg m/21, m/37)
.303 British (7.7x56mmR)
7.62x51mm NATO
Action: Gas-operated, tilting breech block
Rate of fire: 500–650 rounds/min (M1918, M1922, M1918A1)
300-450 or 500-650 rounds/min (M1918A2)
600 rounds/min (wz. 1928)
Muzzle velocity: 860 m/s (2,822 ft/s) (M1918, M1922, M1918A1, M1918A2)
853 m/s (2,798.6 ft/s) (wz. 1928)
Effective range : 100–1,500 yd sight adjustments
Maximum range : Approx. 4,500-5,000 yd
Feed system : 20-round detachable box magazine
Sights : Rear leaf, front post
784 mm (30.9 in) sight radius (M1918, M1922, M1918A1)
782 mm (30.8 in) (M1918A2)
742 mm (29.2 in) (wz. 1928)
(STG) Sturmgewehr 44
Weight 5.22 kg (11.5 lb)
Length 940 mm (37 in)
Barrel length 419 mm (16.5 in)
Cartridge 7.92x33mm Kurz
Action Gas-operated, tilting bolt
Rate of fire 500-600 rounds/min
Muzzle velocity 685 m/s (2,247 ft/s)
Effective range 300 m
Feed system 30-round detachable box magazine
Sights Adjustable sights, rear: V-notch; front: hooded post
Maschinenpistole 43, Maschinenpistole 44 dan Sturmgewehr 44 (MP43, MP44 dan StG44) adalah senapan otomatis selective-fire yang dikembangkan oleh Jerman pada Perang Dunia II, dalam program Maschinenkarabiner (karabin mesin) mereka.
MP43, MP44, dan StG44 adalah senapan yang hampir serupa, dengan sedikit perbedaan pada produksi dan waktu pembuatan. Ketiganya dikembangkan dari Mkb 42(H). Perbedaan nama ini ada karena rumitnya penamaan senjata pada era Nazi Jerman. 'StG' adalah singkatan dari Sturmgewehr (senapan serbu, assault rifle), yang menggabungkan sifat-sifat karabin, submachine gun, dan senapan otomatis. Setelah dipakainya StG44, istilah ini menjadi lumrah untuk mendeskripsikan tipe senjata seperti ini.
Senapan ini memakai peluru 7,92 x 33 mm, yang juga dikenal dengan nama 7,92 mm Kurz (berarti 'pendek'). Peluru ini adalah modifikasi dari peluru standar 7,92 × 57 mm Mauser. Melalui kombinasi dengan kemampuan selective-fire, senjata ini menghasilkan semburan setingkat submachine gun, dengan akurasi dan daya setingkat senapan K98 Mauser pada jarak dekat. Walau begitu, StG44 memiliki jangkauan dan daya yang lebih rendah daripada senapan-senapan pada era itu. Karakter ini mengikuti hasil studi yang dipakai oleh Wehrmacht pada saat itu, yaitu bahwa hampir semua pertempuran terjadi pada jarak kurang dari 300 meter dan mayoritas kurang dari 200 meter. Senapan lain dianggap terlalu besar kekuatannya. Senjata StG44 berhasil membuktikan keunggulannya pada Front Timur sewaktu ia banyak dipakai dan dianggap lebih baik daripada senapan lain pada saat itu.
Sebelum memakai nama MP44 atau Stg 44,dia menyandang nama Maschinenkarabiner 43.Senapan tersebut pada awalnya tidak diresmikan oleh Hitler sebelum menunjukan aksinya di Front Timur.Setelah menunjukan kehebatanya,Maschinenkarabiner pun diresmikan oleh Hitler pada tahun 1943 dan mengganti nama menjadi MP43 dan kelak MP44 atau Stg 44. Sebenarnya pemakaian MP44 adalah "sembunyi-sembunyi" kalau-kalau Hitler akan tidak senang dengan senjata tersebut.Angkatan bersenjata Nazi yang menerima senjata tersebut pertama kali adalah, SS Schutzstaffel. Senjata ini pun menjadi favorit SAS Inggris apabila mereka kehabisan peluru Sten atau Brengun.Senjata ini pun dapat menjadi "Light Support Weapon" bagi SAS apabila Brengun mereka habis.
Konon..dari STG-44 inilah yang mengilhami Mikhail Kalashnikov utk menciptakan senapan legendaris AK-47..
===
FG-42, Paratroops Fallschirmjäger rifle
Weight: 4.2 kg (9.3 lb) (Ausführung "E")
4.95 kg (10.9 lb) (Ausführung "G")
Length: 945 mm (37.2 in) (Ausführung "E")
975 mm (38.4 in) (Ausführung "G")
Barrel length: 500 mm (19.7 in)
Cartridge: 7.92x57mm Mauser
Action: Gas-operated, rotating bolt
Rate of fire: Approx. 900 rounds/min (Ausführung "E")
Approx. 750 rounds/min (Ausführung "G")
Muzzle velocity: 740 m/s (2,428 ft/s) (SmK bullet)
Effective range: 450 m
Feed system: 10 or 20-round detachable box magazine
Sights: Iron sights (all models); flip-up front post and folding rear diopter sight; ZFG42 or ZF4 scope
FG-42 hampir sama dgn STG-44 hanya pelurunya setara dgn K98, dan hanya digunakan oleh pasukan Fallschirmjäger (Airbone).
Pict: Battle of Crete
===
USA
M1918 Browning
Weight: 7.25 kg (15.98 lb) (M1918)
Approx. 11 kg (24 lb) (M1922)
8.4 kg (19 lb) (M1918A1)
8.8 kg (19 lb) (M1918A2)
9.0 kg (20 lb) (wz. 1928)
Length: 1,194 mm (47 in) (M1918, M1922, M1918A1)
1,215 mm (47.8 in) (M1918A2)
1,110 mm (43.7 in) (wz. 1928)
Barrel length: 610 mm (24.0 in) (M1918, M1922, M1918A1, M1918A2)
611 mm (24.1 in) (wz. 1928)
Cartridge: .30-06 Springfield (7.62x63mm) (M1918, M1922, M1918A1, M1918A2)
7.92x57mm Mauser (wz. 1928)
7.65x53mm Belgian Mauser (FN Mle 1930, FN Mle D)
7x57mm Mauser
6.5x55mm (Kg m/21, m/37)
.303 British (7.7x56mmR)
7.62x51mm NATO
Action: Gas-operated, tilting breech block
Rate of fire: 500–650 rounds/min (M1918, M1922, M1918A1)
300-450 or 500-650 rounds/min (M1918A2)
600 rounds/min (wz. 1928)
Muzzle velocity: 860 m/s (2,822 ft/s) (M1918, M1922, M1918A1, M1918A2)
853 m/s (2,798.6 ft/s) (wz. 1928)
Effective range : 100–1,500 yd sight adjustments
Maximum range : Approx. 4,500-5,000 yd
Feed system : 20-round detachable box magazine
Sights : Rear leaf, front post
784 mm (30.9 in) sight radius (M1918, M1922, M1918A1)
782 mm (30.8 in) (M1918A2)
742 mm (29.2 in) (wz. 1928)
HandGun
German
Luger P08 pistol
Weight : 1.92 lbs. (871 grams)
Length: 8.75 in. (222 mm)
Barrel length: 98 mm–203 mm (3.9 in–8.02 in.)
Cartridge: 7.65x22mm Parabellum, 9x19mm Parabellum
Action: Toggle-locked, short recoil
Rate of fire: Semi-automatic
Muzzle velocity: 350-400 m/s
Effective range: ~50 m (9mm)
Feed system: 8-round detachable box magazine, 32-round detachable drum
Sights: Iron sights
Walther P38
Weight: 800 g (1 lb 12 oz)
Length: 216 mm (8.5 in)
Barrel length: 125 mm (4.9 in)
Cartridge: 9x19mm Parabellum
Action: Short recoil, locked breech
Muzzle velocity: 365 m/s (1,200 ft/s)
Effective range: Sights set for 25 m (82 ft)
Maximum range: 50 m (164 ft) effective range
Feed system: 8-round detachable single-stack magazine
Sights: Rear notch and front blade post
===
USA
M1911 pistol
Weight : 2.44 lb (1,105 g) empty, w/ magazine (FM 23–35, 1940)
Length: 8.25 in (210 mm)
Barrel length: 5.03 in (127 mm), Government model;
4.25 in (108 mm), Commander model;
3.5 in (89 mm), Officer's ACP model
Cartridge: .45 ACP, .38 Super
Action: Short recoil operation
Muzzle velocity: 830 ft/s (253 m/s)
Feed system: 7 rounds (standard-capacity magazine), +1 in chamber
===
British
Webley Revolver
Weight: 2.4 lb (1.1 kg), unloaded
Length: 11.25 in. (286 mm)
Cartridge: .455 Webley Mk II
Calibre: .455 Webley
Action: Double Action revolver
Rate of fire: 20–30 rounds/minute
Muzzle velocity: 620 ft/s (190 m/s)
Effective range: 50 yd
Maximum range: 300 yd
Feed system: 6-round cylinder
Sights: fixed front blade and rear notch
===
Russia
Tokarev TT-30/33 pistol
Weight: 854 g (30.12 oz)
Length: 194 mm (7.6 in)
Barrel length: 116 mm (4.6 in)
Height: 134 mm (5.3 in)
Cartridge: 7.62x25mm Tokarev
Action: Short recoil actuated, locked breech, single action
Muzzle velocity: 420 m/s (1,378 ft/s)
Effective range: 50 m
Feed system: 8-round detachable box magazine
Sights: Front blade, rear notch 156 mm (6.1 in) sight radius
===
Japanese
Nambu
Weight: 900 g (1.98 lb) unloaded
Length: 230 mm (9.06 in)
Barrel length: 117 mm (4.61 inches)
Width: 720 g
Cartridge: 8x22mm Nambu
Caliber: 8 mm
Action: recoil-spring
Muzzle velocity: 950 ft/s (289.6 m/s)
Feed system: 8 round box magazine
===
Italy
Beretta M 1934
* Weight: 750 g (26.4 oz)
* Length: 150 mm (5.91 in)
* Barrel length: 88 mm (3.46 in)
Cartridge: .380 ACP (9×17mm Browning Short)
Action: blowback
Muzzle velocity: 1,000 ft/s (304.8 m/s)
Feed system: 7-round detachable box magazine
German
stick Grenades Model 24
Panzerwurfmine L. (Anti Tank Grenades)
Cumulative grenade for the pistol
US
MKII Grenade
Japanese Type 91-50 mm Grenade
Soviet
Helmet
German
US Army
British Army
Japanese
Soviet
Anti Tank Rifles
Solothurn S-18-1000 20 mm AT rifle (Swiss/German),
S-18-1100 for automatic type.
Weight 45 kg without magazine
Length 176 cm (85 inches)
Barrel length 92.5 cm (57 inches)
Cartridge 20 mm x 138 mm (Solothurn Long)
Caliber 20 mm
Action semi-automatic
Muzzle velocity 850 m/s
Feed system 10 rounds
PTRS-41 (Russia)
Weight 20.3 kg
Length 2,000 mm
Barrel length 1,219 mm
Crew 2
Cartridge 14.5x114mm
Muzzle velocity 1,013m/s (3,320 ft/s)
Effective range 400 m
Maximum range 800 m
Feed system 5-round magazine
Boys anti-tank rifle (British)
Weight 35 lb (16 kg)
Length 5 ft 2 in (1.575 m)
Barrel length 36 in. (910 mm); Airborne: 30 in. (762 mm)
Cartridge Kynoch & RG .55 Boys (13.9x99mmB)
Calibre .551 in (13.9 mm)
Action Bolt
Rate of fire ~10 round/min
Muzzle velocity 747 (later 884) m/s (2,450.1 ft/s) (2,899.5 ft/s)
Effective range 16-19 mm penetration at 90° 100 yards (91 m)
Feed system 5 round detachable box magazine
Type 97 20 mm (Japanese)
Weight 59 kg
Length 2.06 m
Barrel length 1200 mm
Caliber 20 x 124 mm
Action Gas-operated
Rate of fire 12 round/min
Muzzle velocity 750 m/s (2,460 ft/s)
Feed system 7 round detachable box magazine
Solothurn S-18-1000 20 mm AT rifle (Swiss/German),
S-18-1100 for automatic type.
Weight 45 kg without magazine
Length 176 cm (85 inches)
Barrel length 92.5 cm (57 inches)
Cartridge 20 mm x 138 mm (Solothurn Long)
Caliber 20 mm
Action semi-automatic
Muzzle velocity 850 m/s
Feed system 10 rounds
PTRS-41 (Russia)
Weight 20.3 kg
Length 2,000 mm
Barrel length 1,219 mm
Crew 2
Cartridge 14.5x114mm
Muzzle velocity 1,013m/s (3,320 ft/s)
Effective range 400 m
Maximum range 800 m
Feed system 5-round magazine
Boys anti-tank rifle (British)
Weight 35 lb (16 kg)
Length 5 ft 2 in (1.575 m)
Barrel length 36 in. (910 mm); Airborne: 30 in. (762 mm)
Cartridge Kynoch & RG .55 Boys (13.9x99mmB)
Calibre .551 in (13.9 mm)
Action Bolt
Rate of fire ~10 round/min
Muzzle velocity 747 (later 884) m/s (2,450.1 ft/s) (2,899.5 ft/s)
Effective range 16-19 mm penetration at 90° 100 yards (91 m)
Feed system 5 round detachable box magazine
Type 97 20 mm (Japanese)
Weight 59 kg
Length 2.06 m
Barrel length 1200 mm
Caliber 20 x 124 mm
Action Gas-operated
Rate of fire 12 round/min
Muzzle velocity 750 m/s (2,460 ft/s)
Feed system 7 round detachable box magazine
France
MAS-36 rifle
Weight: 3.7 kg (Empty)
Length: 1,020 mm
Barrel length : 575 mm (22.6 in.)
Cartridge: 7.5 x 54 mm
Action: Bolt-action
Muzzle velocity : 2800 ft/s (853.6 m/s)
Effective range : est. 350-400 yards w/open sights
Feed system: 5 round internal box magazine, clip fed
lebel mle 1886/93, with an APX 1916 scope
Weight 9.73 lb (4.41 kg) (loaded with 10 rounds)
9.21 lb (4.18 kg) (unloaded)
Length 4.28 ft (1.3 m)
Barrel length 2.62 ft (0.8 m)
Caliber 8 mm Lebel
4 grooves, right to left twist
Action Bolt-action
Muzzle velocity 2,000 to 2,300 ft/s(610 to 700 m/s)
Maximum range 3,500 to 4,500 yd (3,200 to 4,100 m)
Feed system 8 round tube magazine
SMG
MAS-38 (MAS Mle 1938)
Weight: 2.87 kg (without magazine) 3.56 kg (with magazine)
Length: 623 mm
Barrel length: 224 mm
Cartridge : 7.65mm Longue, 7.65x17mm Browning SR
Action : Blowback
Rate of fire: 600-700 rounds/min
Muzzle velocity: 350 m/s (1,148 ft/s)
Effective range : 100m
Maximum range : 200m
Feed system : 32 rounds
MAC M. 1924/29 light machine gun
Caliber: 7.5x54 m29
Weight:8.9 kg
Length:1070 mm
Barrel Length:500 mm
Feed:box magazine, 25 rounds
Rate of fire:450-500 rounds per minute
Modèle 1935 pistol
Weight 730 g (A), 790 g (S) (unloaded)
Length 188 mm
Cartridge 7.65mm Longue
Action Single action
Muzzle velocity 304 m/s (997.1 ft/s)
Feed system 8 round, single stack magazine
Sights iron sights
MAB Model D pistol
Weight 0.76 kg
Length 178 mm
Barrel length 101 mm
Caliber 7.65x17mm Browning SR (.32 ACP) and .380 ACP
Action blowback
Muzzle velocity 213 m/s (698.64 ft/s) for .32 ACP
Feed system 9-round box magazine (.32 ACP) and 7 rounds for .380 ACP
Brandt M1927/31 Mortar
Crew: 1
Barrel length: 1267.50 mm | Caliber: 81.40 mm
Weight of barrel: 18.50 kg
Rate of shooting: 20 rounds/min
Elevation: +45° to +85° | Traverse: 8° to 12°
Projectile weight: 3.31 kg or 6.845 kg
Initial velocity: 174 m/s or 158 m/s
Maximum range: 2850 m or 1200 m
F1 grenade
Weight 570 g
Length 90 mm (without fuse)
Filling Cheddite (WWI model)
Filling weight 60 gr
Detonation
mechanism Timed Friction Fuse
Print this page
